Beschreibung
Fiber Count 12 Fibers
Fiber Mode OS2 9/125μm
Front Connector Type LC UPC Duplex (Blue)
Number of LC Port 6 Ports
Rear Connector Type US Conec MTP® APC (Pinned)
Number of MTP® Port 1 Port
MTP Adapter Key up to Key down
Housing Type Cassette
Material of Sleeve Zirconia Ceramic
Material of Cassette Body Aluminium (AL5052)
Polarity Type A (A and AF used as a Pair)
Dimensions (HxWxD) 1.38''x4.29''x4.64'' (35x109x118mm)
Insertion Loss MTP≤0.35dB, LC≤0.2dB
Return Loss MTP≥60dB, LC≥50dB
Standard RoHS Compliant
Application Matching for FHD Series Enclosures
