LC UPC to LC UPC Flat Clip Uniboot Duplex OM4 Multimode (LSZH) 2.0mm BIF Fiber Optic Patch Cable
LC UPC to LC UPC Flat Clip Uniboot Duplex OM4 Multimode (LSZH) 2.0mm BIF Fiber Optic Patch Cable
SKU: TP-FPH-470
100 in voorraad
Verkocht: 0Couldn't load pickup availability
Connector Type LC UPC to LC UPC
Fiber Grade Corning BIF Fiber
Fiber Mode OM4 50/125μm
Wavelength 850/1300nm
Insertion Loss ≤0.2dB
Return Loss ≥20dB
Attenuation at 850nm 3.0 dB/km
Attenuation at 1300nm 1.5 dB/km
Fiber Count Duplex
Cable Diameter 2.0mm
Min. Bend Radius (Fiber Core) 7.5mm
Min. Bend Radius (Fiber Cable) 20D/10D (Dynamic/Static)
Tensile Strength (Long Term/Short Term) 60N/100N
Cable Jacket (LSZH)
Durability 500 Cycles
Polarity A (Tx) to B (Rx)
Operating Temperature -20 to 70°C
Storage Temperature -40 to 80°C
Connector Push Pull Tab LC to Push Pull Tab LC
Jacket OD 2.0mm
Fiber Mode OS2 SMF
Polish Typs ≥50dB
Fiber Class G.657.A1
Min Bend Radius 10mm
Operating Temperature -20 to 70°C
Storage Temperature -40 to 80°C
Connector Push Pull Tab LC to Push Pull Tab LC
Jacket OD 2.0mm
Fiber Modhgfterial (LSZH)
Insertion Loss ≤0.2dB
Return Loss ≥50dB
Fiber Class G.657.A1
Min Bend Radius 10mm
Operating Temperature -20 to 70°C
Storage Temperature -40 to 80°C
