MTP-12 - 12x LC (6x duplex LC) Fiber Optic Patch Cord, Female, Elite 12F OM4 Violet LSZH 3.0mm Jacket, Corning Fiber
MTP-12 - 12x LC (6x duplex LC) Fiber Optic Patch Cord, Female, Elite 12F OM4 Violet LSZH 3.0mm Jacket, Corning FiberSKU: TP-MTPM-1283
Sale
Sold out
Regular price
€85,00 EUR
Regular price
Sale price
€85,00 EUR
Unit price
per
Excl. VAT
Shipping calculated at checkout.
100 in stock
-
- 1-Year Warranty
-
- Would you like to place a larger order? Send an email to sales@telcoparts.com
Couldn't load pickup availability
Description
MTP® trunks are fully factory pre terminated and extensively tested, and are equipped with reliable MTP® to MTP® or MTP® to LC Uniboot connectors. Thanks to ultra low loss MTP® connectors, signal loss during transmission is minimized, supporting long distance connections and multiple connection points.
The robust double jacket provides additional protection against crushing, ensuring durability and stable performance over longer distances. These features make MTP® trunks the ideal solution for high density cabling in data centers.
SPECIFICATIONS: |
| Connector A | MTP® Elite Female (no pins) |
| Connector B | LC Duplex Uniboot |
| Fiber mode | OM4 50/125 μm |
| Wavelength | 850/1300 nm |
| Fiber | Bend insensitive fiber |
| Minimum bend radius | 7.5 mm |
| Polish type | UPC to UPC |
| Polarity | Type B |
| Cable jacket | Plenum (OFNP) |
| Cable structure | Double jacket |
| Number of fibers | 12 fibers (Base 12) |
| Breakout length | 0.5 m |
| Outer diameter cable (OD) | 3.6–4.5 mm |
| Outer diameter breakout (OD) | 2.0 mm |
| Number of MTP connectors | 1 |
| Number of LC connectors | 6 |
| MTP connector insertion loss (IL) | ≤ 0.20 dB |
| LC connector insertion loss (IL) | ≤ 0.15 dB |
| MTP connector return loss (RL) | ≥ 27 dB |
| LC connector return loss (RL) | ≥ 20 dB |
| Attenuation at 850 nm | ≤ 2.3 dB/km |
| Attenuation at 1300 nm | ≤ 0.6 dB/km |
| Long term tensile load | 100 N |
| Short term tensile load | 300 N |
| Operating temperature | -10 to 60 °C (14 to 140 °F) |
| Storage temperature | -10 to +70 °C (14 to 158 °F) |
